Model HP Voltage Hertz Amps Flow Rate GPM
NE4523 0.75 115 60 5.5 38GPM
NF4268 0.33 115 60 2.5 24GPM
NEP4269 0.50 115 60 4.5 35GPM
NE4524 1.50 115 60 15.5 115GPM
NEP4271 1.0 115 60 11.0 90GPM
FX PRIME SINGLE SPEED PUMPS TECHNICAL DATA
page 15
Key Key Part Name Qty Manf. No. B.W. No.
1 25 WATER PUMP 1 SPS31600 NEP4272
TRANSPARENT COVER CLOSING
1
2
7
8
9
10
11
12
3
6
4
5
Key Part Name Qty Manf. No. B.W. No. For Model#
1 Water Pump/ Motor 1 SPS1A250, 450,550
NEP4268-
NE4523, NEP4268- NEP4269
Transparent Hair & Lint Strainer
Cover
3 41 1 1/4"- 1 1/2" Hose Connector 2 P00132 NEP4246 All
4 42 O-ring "A"- 2 1/4" 1 P00182 NEP4265 All
5 43 O-ring "B"- 3" 1 P00183 NEP4266 All
6 44 O-ring "C"- 1.5" 1 P00184 NEP4267 All
7 45 Strainer Collar 1 P00133 NEP4247 All
8 46 Strainer Basket 1 P00134 NEP4248 All
9 47 Pump Drain Cap 1 P00135 NEP4249 All
10 48 Drain Valve O-ring 1 P00136 NEP4250 All
11 51 Motor Pump Seal 1 P00137 NEP4251 NE4523
11 51 Motor Pump Seal 1 P00138 NEP4252 NEP4268
11 51 Motor Pump Seal 1
P00138 NEP4252 NEP4269
12 52 Impeller Assembly 1 P00139 NEP4253 NE4523
12 52 Impeller Assembly 1 P00140 NEP4254 NEP4268
12 52 Impeller Assembly 1 P00140 NEP4254 NEP4269
13 53 Shaft Seal & S
pring Assbly 1 P00141 NEP4255 NE4523
13 53 Shaft Seal & Spring Assbly 1 P00142 NEP4256 NEP4268
13 53 Shaft Seal & Spring Assbly 1 P00142 NEP4257 NEP4269
1
10
9
7
8
6
5
4
2
3
2
FX PRIME SINGLE SPEED NE4523, NEP4268, NEP4269
PUMP SERIES PARTS BREAKDOWN
1
2
7
8
9
10
11
12
3
6
4
5
FX PRIME SINGLE SPEED NE4524, NEP4271 PUMP
SERIES PARTS BREAKDOWN
13
12
11
For Model#
NE4524 & NEP4271
O
