Blue Wave NB19909 - Page 14

14
7
10. FOR 18’ POOLS ONLY! Insert the Pins (6) down through the top of the T-Fittings until the Pins snap into
place on the lower side of the T-tting.
WARNING: The spring pin must be completely seated in the hole of the T-Fitting or your pool will collapse
when you ll with water. This would be an incorrect assembly and would void your warranty.
11. Carefully slide the Vertical Legs (3) up through the belt that runs around the pool. TIP: For smaller pools
without a belt, slide the vertical legs up through the sleeves on the pool wall.
3
3
3
3
POOL ASSEMBLY INSTRUCTIONS (CONTINUED)
6
