5.3. Upstream Protection
CAUTION!
The blueberry PLUS charging station protection devices outside the charger are to be
done according to the local regulations and codes.
Power Unit
i-charging recommends an upstream short circuit protective device for each power
unit according to the following table:
CE North America
Power
Short circuit protective device
Power
Short circuit protective device
50kW
125A 3P C curve, >16kA
50kW
125A 3P C curve, >16kA
100kW
250A 3P C curve, >16kA
100kW
200A 3P C curve, >16kA
150kW
320A 3P C curve, >16kA
150kW
300A 3P C curve, >16kA
200kW
400A 3P C curve, >16kA
200kW
400A 3P C curve, >16kA
i-charging also recommends using a residual current device of 300mA Type A.
blueberry PLUS - User Unit
i-charging recommends an upstream installation of a short circuit protective device of 10A
3P C curve, 10kA rated short-circuit breaking capacity.
i-charging also recommends using a residual current device of 30mA Type A.
