● To use the pump in dual action mode (the pump will inflate or deflate
on both the upwards and downward pump stroke) make sure the
action attachment is fixed into the inlet by twisting clockwise until
tightened fully. Figure 3 - Use this function when adding/removing
large volumes of air quickly.
● To use the pump in single action mode (the pump will only inflate or
deflate on the downward pump stroke) remove the action attachment
by twisting anti-clockwise until the inlet is open and free. Figure 4 -
Use this function when inflating at high pressure, at the latter end of
the inflating process.
● To use the pump for inflation, fix
the hose by turning clockwise
onto the pump air outlet labelled
inflate Figure 1 or to use the
pump for deflation fix the hose
by turning clockwise onto the
pump air outlet labelled deflate.
Figure 2
Single Chamber Pump
S WIFT P R O
PUMP
