Blueridge BM12MCD - Unit Parts; Identification of Indoor and Outdoor Components

1
2
3
4
5
6
6
7
1. Air outlet
2. Air inlet
3. Electric control cabinet
4. Drain pipe
5. Connecting pipe
6. Air inlet
7. Air outlet
7
Unit Parts
NOTE ON ILLUSTRATIONS
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit
may be slightly dierent. The actual shape shall prevail.
Fig 2.1
NOTE: The installation must be performed in accordance with the requirement of local and national
standards. The installation may be slightly dierent in dierent areas.
Unit Parts
 Page 15 
Revised 5/14/2020
