CMX44CS USER MANUAL
www.blustream.com.au | www.blustream-us.com | www.blustream.co.uk16
Schematic
Example Schematic
RS-232 HDMI CAT Cable Network Connection Optical Digital Stereo Audio IR
HMXL88ARC
Maximum of 8 x 4K 60Hz 4:4:4 Sources
AVR
Control Processor
1 2 3 4 5 6 7 8
24V PoC HDMI IR RS-232 ARC
RX70CS
RX70CS
1080p to 70m, 4K to 40m Max
Max 8 x 4K Displays via HDBaseT™
4K Projector
4K Display
For 24V PoC, HDMI ARC and Optical Audio Return functionality,
the RX70CS HDBaseT™ receiver must be used.
UPDATE WITH
CMX44CS
SCHEMATIC
