Bluetti B230 - 9. AC200 MAX + B230 EXTRA BATTERYS; Hotswap Expansion Battery Setup

08
9.AC200MAX + B230 EXTRA BATTERYS
a: Button 01
b: Switch 02
(AC200MAX + *1 B230 = 4096Wh Capacity)
（AC200MAX with *2 B230 = 6144Wh)
(Hotswap expansion battery easy setup.)
Step 1: Turn ON/OFF B230.
Step 2: Press the button(a) and fully plug Battery Expansion Cable
into the battery port of AC200Max.
Step 3: Push forward the switch(b) to lock the connection.
