10.TECHNICAL SPECIFICATIONS
General Specs
Model No. B230
Net Weight 21.8kg (48.0lbs)
Dimensions 420*280*227.5mm (16.5*11.0*8.91in)
Charge Temperature 0-40℃ (32-104 ℉ )
Discharge Temperature -20-40℃ (-4-104 ℉ )
Storage Temperature -20-40℃ (-4-104 ℉ )
Working Environment
Humidity
10-90%
Capacity 2048Wh (40Ah)
Battery Type LiFePO4
Standard Battery Voltage 51.2VDC
DC Output
Cigarette Lighter Port * 1 12VDC/10A
USB-A * 1 3.6-12VDC, 3A,18W
USB-C * 1
5-15VDC,3A;
20VDC,5A,100W
Adapter(T500)
AC input 100-240VAC,50/60Hz,7.5A MAX
DC Output 58.8VDC, 8A
Solar power (D050S)
MPPT(single) Voltage Limit 12-60VDC
Max. Power of Input 500W MAX
Max Input Current 10A MAX
DC Output 16-60VDC, 8.2A MAX
Specs
58.8VDC, 8A
Battery Expansion Port *1
