6.1 AC180T + B70
The AC180T is compatible with up to 2 B70 units, providing a total capacity of up to
1433.6Wh. To connect them:
Step 1: Make sure the B70 is turned off and insert it into the AC180T's battery compartment,
as shown below.
Step 2: Power on the AC180T and the B70 turns on automatically. The ( ) displays on the
AC180T's screen.
6.2 F045D + B70
The F045D operates with one B70 unit, reaching a capacity of up to 716.8Wh. To connect
them:
Step 1: Insert it into the battery compartment, as shown below.
Step 2: Power on the F045D and the B70 turns on automatically. The ( ) displays on the
F045D's screen.
6. Connection
JUST POWER ON 13
EN
