Operation- LCD Display
a: ECO Mode
b: Turbo Charging
c. Low-battery Alert
d: Input Power (W)
e. Output Power (W)
f: Battery Capacity/SOC
g. AC Frequency 50/60Hz)
h. Temperature Alarm
i. Short-circuit Alarm
j. Overload Alarm
k. Remaining Time Indicator
l. UPS Indicator
m. AC Indicator
n. DC Indicator
Turbo Charging:
1. Fast charging mode: AC+PV, total 430W Max, Single AC Input 340W Max, @10-45C;
2. Standard mode: 268W Max, @10-45C;
3. Silent mode: 100W Max;
Power limit:
1. 150W MAX, @45-48C or battery pack voltage at 24-24.2V: 2.
2. 100W MAX,@<10C or battery voltage is less than 19.5V or greater than 24.2V:
g. AC Frequency 50/60Hz)
UPS Indicator:
Connect the EB3A with the AC power and the 'UPS' will be on display. Then Turn-ON
the AC output. When on this mode, the AC power will directly support the loads on
AC output ports and charge the EB3A.
If your AC wall power goes out, the unit switches to using the battery almost within
20ms instantaneously
