Ordering InformationSERVO-DRIVE for
AVENTOS HL
Power Supply Set - see page 12
D
NOTE: For additional AVENTOS HL components and installation instructions,
please see AVENTOS brochure (LIT. AVT1000)
SERVO-DRIVE set
Set includes:
▀ Drive unit
▀ 60" universal cable
▀ Cable connector
▀ Cable end protector (qty 2)
Part no.
SERVO-DRIVE set
21FA000
Cover set
Set includes:
▀ SERVO-DRIVE cover plate (left)
▀ Cover plate (right)
▀ Non-handed cover cap (qty 2)
▀ SERVO-DRIVE switches (qty 2)
▀ Ø5 mm Blum distance bumper (qty 4)
▀ Color: gray
Part no.
Cover set
21L8000.NA
Arm assembly set
Set includes:
▀ SERVO-DRIVE arm assembly (left)
▀ Standard arm assembly (right)
▀ Stabilizer rod cover cap (qty 2)
Cabinet height
Part no.
300 to 349
21L3200.01
350 to 399
21L3500.01
400 to 550
21L3800.01
450 to 580
21L3900.01
A B C
NOTE: Stabilizer rod
cutting dimension
for SERVO-DRIVE
application is length =
interior cabinet width
minus 164 (6-7/16")
B
B
A
B
B
C
D
