Mountingandcommissioning
V2A|04/2018
14
©byBlum‐Novotest
Fig.3‐5Universalholder
Fig.3‐6Front‐Kit/Adapter15°/30°
Fig.3‐7Lightprotectionshield
11
60°
27
19
8,5
22
16
M6 Ø5,2
(11) Clampingscrew
M
d
=1.5Nm
142684 (15°)
142677 (30°)
15°/30°
142676
Pleasefinddetaileddesignsanddimensionsinthedatasheets.
142678
360°
Pleasefinddetaileddesignsanddimensionsinthedatasheets.
