BLUM IC56 User Manual

Systemoverview
©byBlum‐Novotest
9
V2A|04/2018
2.6 Completesystem
Fig.2‐5
IC56/IC57:
•SwitchON/OFFviaIRflash
•SignaltransmissionforTCseries
•TouchprobeTCandtoolsettingprobeIRcanalternativelybeprogrammedtoTCorDUO.
2.7 Systemcoding
Thecolourcode is the connectionbetweentheprogrammedmeasuring systemandthema‐
chine.
Forcustomer‐specificcodesthewhitelabelcanbemarked.
NOTICE
Riskofcollisionduetolackoflabellingpossible.
 Inordertoavoidmistakesthemeasuringsystemandthemachinemustbecoded.
 Pleasealwaysusethetransparentlabeltoprotect!
Fig.2‐6
IC56
battery o.k.
battery low
www.blum-novotest.com
IC56-TC IC56-DUO
send flash
initial position
probe deflected
Probe 2:
Probe 1:
Mode
standby
mode TC
mode DUO
no reception
interference
reception o.k.
incorrect system
IC56/IC57
- IF59
IC56 - TC
IC56 - DUO
Blum-Novotest
Art.Nr.988350040
GN
BU
GN
BU
+
