SERVO-DRIVE uno
Instruction leaet
SERVO-DRIVE transformers provide power to the drive unit. SERVO-DRIVE transformer function can
be checked via the operating mode indicator (LED).
SERVO-DRIVE transformers
Operating mode display (LED)
Serial tag
1
2
➢ Improper use may cause SERVO-DRIVE for pull-out systems to wear prematurely!
➢ Do not press or pull with force against the movement direction when opening or closing the
drawer.
NOTE
