SERVO-DRIVE uno
Instruction leaet
Orientation diagram: bottom mount waste bin solutions
Orientation diagram: top mount waste bin solutions
SERVO-DRIVE uno supports the opening of drawers.
SERVO-DRIVEuno for TANDEMBOX
SERVO-DRIVEuno
SERVO-DRIVE unit pre-mounted:
Bracket profile horizontal
Bracket profile adapter
Drive unit
Protection against dripping water
Blum transformer including cable
Blum-Distance bumper
1
2
3
4
5
6
SERVO-DRIVE unit pre-mounted:
Attachment bracket
Drive unit
Transport protection
Protection against dripping water
Blum transformer including cable
Assembly device
Blum-Distance bumper
1
2
3
4
5
6
7
