BLUM SERVO-DRIVE

1
2
3
4
5
8
6
7
1
2
3
4
6
7
5
15
EN
Drive unit
Catch plate
Mounting plate
Front fixing
Blum distance bumper
Assembly jig
Front cover
Chipboard screws
Drive unit
Catch plate
Mounting plate
Front fixing
Assembly jig
Front cover
Chipboard screws
Orientation diagram
SERVO-DRIVE flex for refrigerators and freezers
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
Orientation diagram
SERVO-DRIVE flex for dishwashers
SERVO-DRIVE flex allows handle-less refrigerators and freezers to be opened electromechanically by
pressing the front.
SERVO-DRIVE flex allows handle-less dishwashers to be opened electromechanically by pressing
the front.
