CONTRACTOR SERIES
C44CS-KIT/C66CS/C88CS USER MANUAL
contact: support@blustream.com.au | support@blustream-us.com | support@blustream.co.uk
03
Our Contractor 4x4, 6x6 & 8x8 HDBaseT™ CSC Matrix units oer unprecedented
performance and value for the custom installation market. The C44CS-KIT, C66CS
and C88CS are 4K 60Hz 4:4:4 HDCP 2.2 Matrix units deliveringHDMI, bi-directional
IR and PoC up to lengths of 70m (at 1080p) over a single CAT cable.
These Matrix products also provide advanced features including simultaneous
HDBaseT™ / HDMI on output 1 and a web browser interface module for control
and configuration of the unit.
Introduction
FEATURES:
• Advanced HDBaseT™ technology oering uncompressed video and audio with zero latency
• Features 4 x (C44CS), 6 x (C66CS) or 8 x (C88CS) HDMI inputs which can be independently routed to 4 x (C44CS), 6 x
(C66CS) or 8 x (C88CS)HDBaseT™ outputs
• Output 1 features simultaneous HDMI and HDBaseT™ output
• Extends HDMI up to a distance of 70m over single CAT cable
• Supports 18Gbps 4K 60Hz 4:4:4 UHD video up to 40m
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD
Master Audio transmission
• Web interface module for control and configuration of the Matrix unit
• Supports bi-directional IR on all HDBaseT™ outputs
• Supplied with Blustream IR Receivers and Emitters
• Control via front panel, IR, RS-232, TCP/IP and free iOS / Android Apps
• Supports PoC (Power over Cable) to power compatible & supplied (C44CS-KIT only) HDBaseT™ Receivers
• 3rd party drivers available for major control systems
• Advanced EDID management
• HDCP 2.2 compliant
