CUSTOM PRO MATRIX USER MANUAL
COMMAND ACTION
EDID xx CP yy
Set input:xx EDID copy from output:yy
EDID xx DF zz
Set Input:xx EDID To Default EDID:zz
xx=[00]: All INPUT Port, [01...06]: INPUT Port
yy=[01...06]: OUTPUT Port
zz=00: HDMI 1080p@60Hz, Audio 2ch PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1ch DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1ch DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2ch PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1ch DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1ch DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2ch PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1ch DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1ch DTS/DOLBY/HD
zz=09: HDMI 4K@30Hz 4:4:4, Audio 2ch PCM
zz=10: HDMI 4K@30Hz 4:4:4, Audio 5.1ch DTS/DOLBY
zz=11: HDMI 4K@30Hz 4:4:4, Audio 7.1ch DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: User EDID 1
zz=16: User EDID 2
zz=17: GUI Download EDID
zz=18: HDMI 4K@60Hz 4:2:0, Audio 2ch PCM
zz=19: HDMI 4K@60Hz 4:2:0, Audio 5.1ch DTS/DOLBY
zz=20: HDMI 4K@60Hz 4:2:0, Audio 7.1ch DTS/DOLBY/HD
EDID SAVE yy
TO ss
Save output:yy EDID to user memory:ss
ss=[01...02]: User EDID memory
MXSTA
Print matrix IR and RS-232 connect state
MXIR xx FR yy
Remote RX:xx IR output from local IR in:yy
xx=[00]: All remote IR output, [01..16]: Remote RX IR output
yy=[01..16] Local IR in
MXIR GI (+-)xx
Global all IR In signal goes to which IR output:xx
xx=[17..32]: Local IR output
xx=[33..48]: Remote HDBT receiver IR output
+: Add xx to current setting
-: Remove xx from current setting
MXIR GO (+-)xx
Global all IR Out signal goes to which IR input:xx
xx=[17..32]: Local IR input
xx=[33..48]: Remote HDBT receiver IR input
xx=[49]: Global all IR in
+: Add xx to current setting
-: Remove xx from current setting
RS-232 and Telnet Commands
