MFP31 QUICK REFERENCE GUIDE
contact: support@blustream.co.uk | support@blustream.com.au
03
Input Switching
The MFP31 will auto-switch on connection, or on powering of an already connected source to the unit. Inputs can
be manually switched by pressing the source button on the top of the unit. When switching using the manual source
selection button, the unit will scroll from the current source to the next available connected source, in the order of the
physical input connections:
USB-C > HDMI > MINI-DP > USB-C > HDMI ....
The LED ring surrounding the source input button on the top of the unit will be illuminated in blue when connected to
a source that is outputting a video / audio stream. When switching, the LED ring will turn red whilst the unit establishes
a new connection from the next available source device connected.
To help with identification of the source device or input during switching, the LED ring will blink a number of times to
communicate the new source input being passed to the HDMI output:
- 1 Blink - USB-C
- 2 Blinks - HDMI
- 3 Blinks - Mini DisplayPort™
Package Contents
Specifications
MFP31
• 1 x MFP31
• 1 x 5V/1A USB Power Supply
• 1 x USB to Micro-USB Charging Cable
• 1 x Quick Reference Guide
Acknowledgements
DisplayPort™ and the DisplayPort™ logo are trademarks owned by the Video Electronics Standards Association (VESA®)
in the United States and other countries.
NOTE: Specifications are subject to change without notice. Weights and dimensions are approximate.
• Video Input Connectors: 1 x HDMI Type A, 19-pin, female; 1 x USB-C Type C, female; 1 x Mini DisplayPort™, female
• Video Output Connectors: 1 x HDMI Type A, 19-pin, female
• Local Power Input: 1 x Micro USB, female
• Casing Dimensions (Dia x H): 105mm x 25mm
• Shipping Weight: 0.6kg
• Operating Temperature: 32°F to 104°F (-5°C to +55°C)
• Storage Temperature: -4°F to 140°F (-25°C to +70°C)
• Power Supply: 5V/1A DC USB
