MX88ED User ManUa
l
06
contact support@blustream.co.uk / support@blustream.com.au
Package Contents:
• 1 x MX88ED
• 1 x 12V/5A DC power supply
• 1 x Remote control
• 1 x IR Receiver
• 1 x mounting kit
• 1 x manual
Maintenance
Clean this unit with a so, dry cloth. Never use
alcohol, paint thinner or benzene to clean this unit.
Specifications
Video Input Connectors: 8x HDMI Type A, 19-pin,
female, locking
Video Output Connectors: 8x HDMI Type A, 19-pin,
female, locking
RS-232 serial port: DB-9, female
TCP/IP Control: RJ-45, female
IR Input ports: 1x 3.5mm stereo jack
Rack-Mountable: 1 U rack height,
rack ears included
Dimensions (W x D x H): 428mm x 245mm x 43mm,
without feet
Shipping Weight: 2.7kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
Power Supply: 12V/5A DC
RS232 Pin Assignment
MT0404-a40 reMOTe cOnTrOl cOnsOle
PIN Assignment PIN Assignment
1 NC 1 NC
2 Tx 2 Rx
3 Rx 3 Tx
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
Baud Rate: 57600 bps
Data Bit: 8-bit
Parity: None
Stop Bit: 1-bit
Flow Control: None
