BMC G2S BPAP Series User Manual

G2S BPAP Series User Manual V2.1
24 / 43
Fig. 14-4
Note: The above interface only applies to G2S B25T, G2S B25VT, G2S B30T, G2S B30VT, G2S
B30AT and G2S LAB.
14.1.2 Bringing up the Initial Setup Interface
From the Main Interface shown in Fig. 14-1 or Fig. 14-2 or Fig. 14-3 or Fig. 14-4, press and
hold the Ramp Button for three seconds. The screen displays the Initial Setup
Interface of the Patient Menu, as shown in Fig. 14-5.
Fig. 14-5
The first icon on the left side of the screen indicates the Main Interface, the second icon
indicates the Initial Setup Interface, and the third icon indicates the iCode Interface.
As you turn the Knob , the cursor switches among the three icons, and the interface
displayed on the screen changes accordingly.
14.1.3 Accessing the Setup Interface
When the cursor is on the icon , the screen displays the Setup Interface. Access the Setup
Interface by pressing the Knob . The first option on the Setup Interface is then displayed
in blue, as shown in Fig. 14-6.
Fig. 14-6
14.1.4 Selecting Options
As you turn the Knob clockwise, the cursor moves downwards from one option to
another. As you turn it counterclockwise, the cursor moves upwards. When the cursor is on a
