BMC Race Application Dropper - Saddle Height Adjustment

3
Saddle Height Adjustment
Allen Keys
Measuring Tape
Torque Wrench
Time Required
3 minutes
3.1 Tools required
3.2 Saddle Height Reference Table
Saddle height is measured
from the center of bottom
bracket to top of the saddle
Size
Min
Saddle
Height
Max Saddle
Height
Adjustment
Range
Small 655 mm 745mm
90mm
Medium 700 mm 790mm
Large 740 mm 830 mm
Extra Large 770 mm 860mm
5
