Service Manual for RESmart
®
CPAP and AutoCPAP V1.5
Fig. C – Power PCBA (front side) Fig. D – Wire connecting on
power PCBA
Sockets figuration
Fig. E – Power supply connecting
Blue
Brown
AC Socket 3-pin plug
6-pin plug 2-pin plug Reed
Orange
Orange
Black
Black
