BMC RESmart

4
Service Manual for RESmart
®
CPAP and AutoCPAP V1.5
2. Structure
2.1 Outer Illumination
2.2 Inner Construction
See appendix A
2.3 Spare Part
See appendix B
Handle
DisplayScreen
Humidier
Controller
User Buttons
Air Outlet
Humidier
Power
Medical
Product Note
(bottom)
AC Inlet
SD Card
Filter Cap
& Filter
Outlet
Port
Fill Line
Water
Chamber
Heater
Plate
Indicator
Light
