Table 3: Electrical Data
Model Motor size
Three phase
Motor size
Single phase
Motor rated
supply fuse
(Three phase)
Control Fuse Motor rated
supply fuse
(Single Phase)
18 750w 550w 10 Amps 5 Amps 10 Amps
23 750w 550w 10 Amps 5 Amps 10 Amps
30 750w 550w 10 Amps 5 Amps 10 Amps
44 750w 550w 10 Amps 5 Amps 10 Amps
59 750w 550w 10 Amps 5 Amps 10 Amps
88 750w 750w 10 Amps 5 Amps 10 Amps
117 1.5kw N/A 15 Amps 5 Amps 15 Amps
147 2.2kw N/A 15 Amps 5 Amps 15 Amps
176 5.5kw N/A 20 Amps 5 Amps 30 Amps
205 5.5kw N/A 20 Amps 5 Amps 30 Amps
235 7.5kw N/A 30 Amps 5 Amps 30 Amps
293 7.5kw N/A 30 Amps 5 Amps 30 Amps
440 2 x 5.5kw N/A 30 Amps 5 Amps 30 Amps
513 2 x 7.5kw N/A 30 Amps 5 Amps 30 Amps
586 2 x 7.5kw N/A 30 Amps 5 Amps 30 Amps
733 Special Requirements On application - -
880 Special Requirements On application - -
952 Special Requirements On application - -
Controls: BMM Heaters can supply controls for these heaters upon request.
Please confirm with us the type of controls prior to connecting to check
compatibility.
The Burner wiring diagrams can be found in the burner supplement provided with
this manual.
Note: All heaters have been electrically tested at BMM Heaters factory.
