BMM Heaters BMG - General Technical Table 1

Section 4: General Technical Table 1
Model
Min
Air
flow
m³/sec
Max
Air
flow
m³/sec
Heat
Input
kW
Heat
Output
kW
Max Start
Gas Rate
m³/hr
Gas
Flow
Rate
m³/hr
Flue
Spigot
Nominal
Ø mm
Flue
Size
Ø mm
Weights
External
Heater
Kg
Weights
Internal
Heater
Kg
12 .37 .75 15 12 0.36 1.5 154 150 75 66
15 .37 .75 19 15 0.432 1.8 154 150 75 66
18 .37 .75 23 18 0.44 2.2 154 150 75 66
23 .47 .75 30 23 0.7 2.9 154 150 75 66
30 .75 .75 38 30 0.94 3.9 154 150 75 66
44 .82 1.55 57 44 1.08 5.4 154 150 207 192
59 1.13 1.55 75 59 1.75 7.3 154 150 207 192
88 1.55 1.55 113 88 2.62 10.9 154 150 207 192
117 2.11 2.58 150 117 3.48 14.5 204 200 246 228
147 2.58 2.58 188 147 4.18 17.4 204 200 246 228
176 3.19 5.17 225 176 5.23 21.8 204 200 420 384
205 3.75 5.17 263 205 6.1 25.4 254 250 420 384
235 4.23 5.17 300 235 6.98 29.1 254 250 420 384
264 4.75 5.17 338 264 7.85 32.7 254 250 420 384
293 5.17 5.17 376 293 8.71 36.3 254 250 420 384
352 6.23 6.23 451 352 10.32 43 304 300 1704 1364
440 8.46 10.34 537 440 13.08 54.5 304 300 1704 1364
513 9.40 10.34 658 513 15.24 63.5 304 300 1704 1364
586 10.34 10.34 752 586 17.42 72.6 354 350 1704 1364
733 13 16.53 939 733 19.34 80.6 406 400 2304 2160
880 15.35 16.53 1127 880 26.14 108.9 406 400 2304 2160
952 16.53 16.53 1221 952 28.32 118 406 400 2304 2160
Each appliance has been range rated; burner pressures can be found on the data
plate and the burner pressure once commissioned must be entered in the actual.
