length of time to pass without
making further changes.
To switch off the heated grips,
repeatedly press button 1 un-
til heated grip symbol 2 is no
longer shown on the display.
Seat
Removing seat
Make sure the ground is level
and firm and place the motor-
cycle on its stand.
Remove the screw with motor-
cycle seat key 2.
Pull seat 1 to the rear and re-
move.
Installing seat
Position seat 1 in the middle
and push it forward into lugs 4.
Install screw 3 with motorcycle
seat key 2.
4
54
z Operation

BMW Motorrad R nineT/5 Specifications

General

Displacement	1170 cc
Transmission	6-speed
Seat Height	805 mm
Compression Ratio	12.0:1
Final Drive	Shaft drive
Front Wheel Travel	120 mm
Rear Wheel Travel	120 mm
ABS	Standard
Front Tyre	120/70 ZR17
Rear Tyre	180/55 ZR17
Bore x Stroke	101 mm x 73 mm
Fuel System	Electronic fuel injection
Front Suspension Diameter	43 mm
Engine Type	Air/oil-cooled flat twin
Power	80 kW (109 hp)
Torque	116 Nm
Fuel Tank Capacity	17 l (4.5 gal)
Engine Details	Air/oil-cooled flat twin (boxer), four-stroke
Fuel Control	Electronic intake pipe injection
Emission Control	Closed-loop 3-way catalytic converter, emission standard EU-4
Frame	Steel tubular frame
Front Suspension	Telescopic fork
Rear Suspension	Swingarm
Front Brake	Double disc
Rear Brake	Single disc
DIN unladen weight, ready for road	221 kg
Frame Type	Steel tubular frame
