BMW C 650 Sport User Manual

Install screws 1.
Brake system
Check brake operation
Actuate right-hand brake lever.
Pressure point must be clearly
perceptible.
Actuate left-hand brake lever.
Pressure point must be clearly
perceptible.
To check the parking brake,
extend the side stand and try
to slide the Maxi-Scooter back
and forth.
It must not be possible to slide
the Maxi-Scooter.
If no clear resistance points can
be felt or if the Maxi-Scooter can
be pushed:
Have the brakes checked at an
authorized workshop, preferably
an authorized BMW Motorrad
retailer.
Check front brake pad
thickness
Make sure ground is level and
firm and place Maxi-Scooter on
its center stand.
Conduct a visual inspection
of the brake pad thickness.
Viewing direction: left and
right between wheel and front
suspension toward brake
pads 1.
8
85
z Maintenance

BMW C 650 Sport Specifications

General

Displacement	647 cc
Torque	63 Nm at 6, 000 rpm
Front Suspension	Upside-down fork, Ø 40 mm
ABS	Standard
Length	2, 180 mm
Wheelbase	1, 591 mm
Top Speed	180 km/h
Engine Type	Liquid-cooled, 2-cylinder, 4-stroke engine
Power	44 kW (60 hp) at 7, 500 rpm
Transmission	CVT (Continuously Variable Transmission)
Rear Suspension	Single-sided swing arm
Front Brake	Dual disc, 270 mm
Rear Brake	Single disc, 270 mm
Seat Height	800 mm
Fuel Capacity	15.5 l
Weight	249 kg
Fuel Consumption	4.6 liters/100 km
Width	877 mm
