18
E46iCCVM/ST039/3/21/00
Hard Top Lock Hall Sensor
The hard top installed hall sensor is positioned on the left hard top lock. It receives power
and ground from the CVM and provides a high signal input when the hard top is installed
on the vehicle. The connector on the top of the lock is used as the power and ground sup-
ply for the rear window defroster of the hard top.
The CVM uses the input signal of the hall sensor to lock out soft top operation while the
hard top is installed.
54E46CVM1400
ART-MV563
HRDTPLCK.CVM
