E88 Complete Vehicle
C
onvertible top system circuit diagram legend
Index Explanation Index Explanation
1
Car Access System (CAS)
12
Switch for the trunk partition
2
Footwell module (FRM)
13
Hall sensor, convertible top storage
compartment lid open
3
Instrument cluster (KOMBI)
14
Hall sensor, windshield cowl locked
4
Center console switch cluster (SZM)
15
Hall sensor, roll bar unclamped
5
IHKA control module
16
Hall sensor, roll bar positioned/raised
6
Junction box electronics (JBE)
17
Hall sensor, roll bar stowed
7
Power distribution box in junction box
18
Incremental sensor
8
Rear distribution box
19
Drive unit for the windshield cowl
locking system
9
Hall sensor, convertible top storage
compartment lid locked
20
Hall sensor, main pillar raised
10
Hydraulic control unit
21
Hall sensor, main pillar stowed
11
Conv
ertible top module (CVM)
