49
E88 Complete Vehicle
C
onvertible top intermediate position and top storage compartment lid open
Sensor State
Hall sensor, main pillar positioned yes
Hall sensor, main pillar stowed no
Hall sensor, roll bar unclamped no
Hall sensor, clamping bar in position (roll bar raised) yes
Hall sensor, roll bar stowed no
Hall sensor, windnield cowl panel closed no
Incremental sensor, windnield cowl locking system motor position Lock opened
Hall sensor, convertible top storage compartment lid locked no
Hall sensor, convertible top storage compartment lid open yes
Microswitch, Trunk partition down position yes
