E88 Complete Vehicle
The instrument cluster is supplied with power by terminal 30g_f.
The legends on the B
us o
verview also apply to the Bus overview with terminal status on
the next page.
Index Explanation Index Explanation
AL
Active steering system
KOMBI
Instrument cluster
ASP
Outside mirror
LWS
Steering angle sensor
CA
C
omfort access
ACSM
Advanced crash and safety management
CAS
Car access system
OC3
Seat occupancy detection mat
CCC
Car communication computer
PDC
Park distance control
CDC
CD changer
QLT
Quality, level,temp, oil sensor
CID
Central information display
RAD
Radio 2
CON
Controller
RLS
Rain/driving light sensor
DME
Digital motor electronics
SBFA
Driver’s door switch cluster
DSC
Dynamic stability control
SDARS
Satellite tuner
DSC-Sen
DSC sensor
SINE
Emergency current siren w/ tilt alarm sensor
EGS
Electronic transmission control unit
SMBF
Passenger’s seat module
EKP
Electric fuel pump control unit
SMC
Stepper motor controller
EWP
Electric water pump
SMFA
Driver’s seat module
FRM
Footwell module
Top-HiFi
Top-HiFi amplifier
FS
Most direct access
TPMS
Tire pressure monitoring system
FZD
Roof function center
TPM-sen
TPMS sensors X4
IBOC
In band on channel (digital radio)
SBX -H
Interface box
IBS
Intelligent battery sensor
MW-SEN
Micro wave sensors
IHKA
Automatic climate control
SZL
Steering column switch cluster
TCU
Telematics control unit
TAGE
Electric outer door handle module
JB
J
unction box
CVM
Con
vertible roof module
