E85 Information/Communication
- 120 -
Fig. 81: Map in 1000 km scale on DVD
The scale bar in the display corresponds to 1000 km
The pointer for the current position has been enlarged to
32x32 Pixels (previously 16x16 Pixels).
Fig. 82: Map in 500 km scale on DVD
The scale bar on the display corresponds to 500 km
Index Explanation
1 Direction indicator (pointing north)
2 Distance to destination
3 Distance to next turn-off
4 Scale bar with map scale data
KT-10518
KT-10520
