E85 Information/Communication
- 64 -
Operating principle
In the EU version, the Telematic Control Unit features a transmit/
receive module that works in the GSM standard with the
frequencies 900/1800 MHz. This means that, in Germany for
example, D1/D2 or E-Plus can be used.
Via the SIM card (Subscriber Identity Module), which is inserted
into the card reader in the eject box, the TCU recognizes which
system is involved and enables the telephone.
- Eject box
The eject box accommodates the cordless handset SBDH while
the vehicle is being driven.
The eject box is fitted in the lid of the centre console between
the seats.
The SIM card reader is located in the eject box. The eject box
takes on the charging function for the batteries of the SBDH.
Fig. 43: Eject box with SBDH
Index Explanation
1 Eject box
2 SIM card reader
3 Cordless handset (SBDH)
4 Unlock button for SBDH
KT-10587
