E85 Information/Communication
- 20 -
Installation location
The rod aerial is mounted on the rear left side panel. The aerial
amplifier is screwed to the aerial from below.
Fig. 17: E85 Installation location of rod aerial
Design
The rod aerial consists of the aerial rod, aerial head and aerial
base with integrated aerial amplifier.
Fig. 18: Design of rod aerial
Index Explanation Index Explanation
1 Aerial rod 3 Body panel
2 Aerial head 4 Aerial amplifier
KT-10641
KT-10121
