BMW F 750 GS User Manual

100 OPERATION
lights up.
with Connectivity
OE
Possible DTC system status
OFF! is displayed.
Release button 1 once the
status has changed.
remains lit.
with Connectivity
OE
The new DTC system
status OFF! appears briefly on
the display.
The DTC function is switched
off.
Switching on DTC
Press and hold down button 1
until the DTC indicator light
changes status.
with Connectivity
OE
Immediately after button 1
is pressed, the DTC system
status OFF! is displayed.
goes out; if self-diagnosis
has not completed it
starts flashing.
with Connectivity
OE
Possible DTC system status ON
is displayed.
Release button 1 once the
status has changed.
remains off or continues
to flash.
with Connectivity
OE
The new DTC system status ON
appears briefly on the display.
The DTC function is switched
on.
ELECTRONIC SUSPENSION
ADJUSTMENT (DESA)
with Dynamic ESA
OE
Possible settings
Dynamic ESA (electronic
chassis and suspension
adjustment) enables you to
adjust rear-wheel damping
to the road surface. Three
damper settings and three
spring preload levels are
available.

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
