209

Remove the front-wheel

stand.

without centre stand

Remove the auxiliary stand.

Place the motorcycle on its

side stand.

Removing rear wheel

Make sure the ground is level

and firm and place the mo-

torcycle on a suitable auxiliary

stand.

Install the rear-wheel stand

( 192).

with centre stand

Make sure the ground is level

and firm and place the motor-

cycle on its centre stand.

Slip wooden chocks or sim-

ilar under the rear wheel to

prevent it from dropping out

after the quick-release axle

has been removed.

Press the brake caliper 1

against the brake disc 2.

Brake pistons are pushed

back.

Remove screw 3 and remove

the wheel speed sensor from

its bore.

Remove axle nut 4 and

washer 5.

Remove chain tensioner 6 and

push the axle in as far as pos-

sible.

Questions and Answers:

Need help?

Do you have a question about the BMW F 750 GS and is the answer not in the manual?

BMW F 750 GS Specifications

General

Displacement	853 cc
Bore x Stroke	84 mm x 77 mm
Power	77 hp (57 kW) at 7, 500 rpm
Torque	83 Nm at 6, 000 rpm
Compression Ratio	12.7:1
Fuel System	Electronic fuel injection
Final Drive	Chain
Frame	Bridge-type frame, steel shell construction
ABS	BMW Motorrad ABS
Length	2, 255 mm
Width	922 mm
Height	1, 225 mm
Wheelbase	1, 559 mm
Wet Weight	224 kg
Fuel Capacity	15 liters
Tyre, Front	110/80 R19
Tyre, Rear	150/70 R17
Engine Type	Water-cooled, 4-stroke in-line two-cylinder engine, four valves per cylinder, two overhead camshafts
Clutch	Multiple-disc wet clutch, mechanically operated
Transmission	6-speed
Front Suspension	Telescopic fork
Rear Suspension	Cast aluminum dual swing arm
Front Brake	Double disc brake
Rear Brake	Single disc brake
Seat Height	815 mm
