Index Explanation Index Explanation
1
Central gateway module
10
Rear power distribution box
2
Mid-range speaker, front center
11
HiFi amplifier
3
Tweeter, front center
12
Tweeter, rear window shelf, left
4
Car Information Computer
13
Mid-range speaker, rear window shelf, left
5
Tweeter, front right door
14
Woofer, under left front seat
6
Mid-range speaker, front right door
15
Mid-range speaker, front left door
7
Woofer, under right front seat
16
Tweeter, front left door
8
Mid-range speaker, rear window shelf, right
K-CAN
Body CAN
9
Tweeter, rear window shelf, right
15
