BMW F01 - HiFi Speaker System

HiFi Speaker System
The digital 7-channel HiFi amplifier is supplied by Lear. The HiFi system consists of a
HiFi amplifier with the 12 speakers. This system is fitted as standard on the F01/F02.
Index Explanation Index Explanation
1
Tweeter, front right door
8
Tweeter, rear window shelf, left
2
Mid-range speaker, front right door
9
Woofer, under left front seat
3
Woofer, under right front seat
10
Mid-range speaker, front left door
4
Tweeter, rear window shelf, right
11
Tweeter, front left door
5
Mid-range speaker, rear
window shelf, right
12
Mid-range speaker, front center
6
Mid-range speaker, rear
window shelf, left
13
Tweeter, front center
7
HiFi amplifier
HiFi Speaker System on the F01/F02
71
F01 Audio Systems
