BMW R 1150 RT Repair Manual

33.9
33 12 Removing needle roller bearing for input
bevel pinion
•
Heat the housing to 120 °C (248 °F).
•
Remove the outer ring of the needle roller bear-
ing using
internal puller, BMWNo.008573, threaded ex-
tension, BMWNo.008575, and counter-sup-
port, BMW No. 00 8 572.
33 12 Installing needle roller bearing for input
bevel pinion
•
Heat the needle roller bearing seat to 100 °C
(212 °F).
•
Press in needle roller bearing using drift or the in-
put bevel pinion.
33 12
Assembling input bevel pinion
•
Clean the threads of the input bevel pinion.
•
Heat the inner race (1) to 100 °C (212 °F) and
push onto input bevel pinion (2) as far as the
stop.
•
Push the outer race (3) together with the roller
cage (4) on to the inner race.
•
Heat ball thrust bearing (5) to 100 °C (212 °F) and
push fully on to input bevel pinion.
•
Allow input bevel pinion to cool down.
S330050
00 8 572
00 8 573
00 8 575
KR330131
1
2
3
4
5
h
100
w
w
h
100

BMW R 1150 RT Specifications

General

Displacement	1130 cc
Transmission	5-speed
Final Drive	Shaft
Bore x Stroke	101 mm x 70.5 mm
Compression Ratio	10.3:1
ABS	Optional
Engine Type	Air/oil-cooled, four-stroke, Boxer twin
Power	95 hp at 7, 250 rpm
Torque	100 Nm at 5, 500 rpm
Dry Weight	259 kg
Front Suspension	Telelever
Rear Suspension	Paralever
Front Brakes	Dual disc
Rear Brakes	Single disc
Wheelbase	1485 mm (58.5 in)
