34.11
Removing and installing front ABS
sensor
•
Remove fuel tank.
•
Separate plug connector (1) in sensor line.
•
Remove sensor (2) with Torx T 25.
•
Install by following the above work instructions in
the reverse order.
e Caution:
Run the sensor line correctly.
Check sensor gap and adjust if necessary with
spacer plate (3).
Sensor gap:............ 0.45...0.55 mm (1.77...2.22 in)
X Tightening torque:
Sensor ..........................................handtight, 4 Nm
C340050
1
3
2

BMW R 1200 C Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Transmission	5-speed
Final Drive	Shaft drive
Rear Suspension	Monoshock
Seat Height	740 mm
Engine Type	Air-cooled, 2-cylinder, 4-stroke boxer engine, one camshaft, four valves per cylinder
Power	61 hp @ 5, 000 rpm
Torque	98 Nm @ 3, 000 rpm
Front Suspension	Telescopic fork
Rear Brakes	Single disc, diameter 285 mm, 2-piston caliper
Fuel Capacity	17 liters
Wheelbase	1650 mm
