BMW R 1200 GS 2014 User Manual

Engine oil
Engine oil, capacity max 1.1 gal (max 4 l), with filter replacement
Specification SAE 5W-40, API SL / JASO MA2, additives (for
instance, molybdenum-based substances) are
prohibited because they would attack the coat-
ings on engine components. BMW Motorrad rec-
ommends that you use the BMW Motorrad oils
available from your BMW Motorrad Dealer.
Engine oil, quantity for topping up max 1 quarts (max 0.95 l), difference between
MIN and MAX
BMW recommends
10
161
z Technical data

BMW R 1200 GS 2014 Specifications

General

Displacement	1170 cc
Bore x Stroke	101 mm x 73 mm
Compression Ratio	12.5:1
Fuel Control	Electronic intake pipe injection
Final Drive	Shaft drive
Front Wheel Travel	190 mm
Rear Wheel Travel	200 mm
ABS	Standard
Front Tire	120/70 R19
Rear Tire	170/60 R17
Wheelbase	1507 mm
Fuel Capacity	20 liters
Weight	238 kg (wet)
Width	953 mm
Height	1450 mm
Engine Type	Flat twin (Boxer)
Power	125 hp @ 7750 rpm
Torque	125 Nm @ 6500 rpm
Clutch	Wet multi-plate clutch, hydraulically operated
Transmission	6-speed
Frame	Two-section frame
Front Suspension	Telelever, central spring strut
Rear Suspension	Cast aluminum single-sided swing arm
Front Brakes	Dual 305 mm discs
Rear Brakes	Single 276 mm disc
Seat Height	850 mm
Length	2207 mm
