BMW R 1200 GS ADVENTURE User Manual

Standard status
indicators
Multifunction display
1 Clock ( 46)
2 Gear indicator ( 20)
3 Engine temperature ( 20)
4 Odometer and tripmeters
( 47)
5 Fuel capacity ( 20)
Telltale lights
1 Flashing turn indicators, left
2 High-beam headlight
3 Idle
4 Flashing turn indicators,
right
Fuel capacity
The horizontal bars below
the fuel-pump symbol in-
dicate the remaining quantity of
fuel.
When the fuel in the tank is
topped up the gauge briefly
shows the original level, before
the reading is updated.
Gear indicator
The gear engaged or N
for neutral appears on the
display.
If no gear is engaged, the
'neutral' telltale light also
lights up.
Engine temperature
The horizontal bars below
the temperature symbol
indicate the engine temperature.
Service-due indicator
If the next service is due in less
than one month, the date for the
3
20
z Status indicators

BMW R 1200 GS ADVENTURE Specifications

General

Displacement	1, 170 cc
Bore x Stroke	101 mm x 73 mm
Max Power	125 hp (92 kW) at 7, 750 rpm
Max Torque	125 Nm at 6, 500 rpm
Compression Ratio	12.5:1
Fuel System	Electronic intake pipe injection
Final Drive	Shaft drive
Front Brake	Dual disc brake, floating brake discs, diameter 305 mm, 4-piston radial calipers
Rear Brake	Single disc brake, diameter 276 mm, double-piston floating caliper
Length	2, 255 mm
Width	980 mm
Height	1, 450 mm
Wheelbase	1, 510 mm
Wet Weight	260 kg
Fuel Capacity	30 liters
Tires Front	120/70 R19
Tires Rear	170/60 R17
Engine Type	Air/liquid-cooled four-stroke flat twin engine, double overhead camshaft, one balance shaft
Transmission	6-speed
Clutch	Hydraulically operated wet clutch
Frame	Two-section frame
Front Suspension	BMW Motorrad Telelever
Rear Suspension	BMW Motorrad Paralever
ABS	BMW Motorrad Integral ABS
Seat Height	890 mm
