BMW R 1200 GS User Manual

Electrical system
Rated load of onboard socket 5 A
Fuses All circuits are electronically protected, so
plug-in fuses are no longer necessary. If an
electronic fuse trips and de-energizes a cir-
cuit, the circuit is active as soon as the ig-
nition is switched on after the fault has been
rectified.
Battery
Battery design AGM (Absorptive Glass Matt) battery
Battery nominal voltage 12 V
Battery nominal capacity 14 Ah
Spark plugs
Spark plug manufacturer and designation Bosch YR5LDE
Spark plug electrode gap
New
0.03
±0.01
in
Spark plug electrode gap
Wear limit
0.04 in
9
129
z Technical data

BMW R 1200 GS Specifications

General

Final Drive	Shaft drive
Curb Weight	238 kg
Wheelbase	1, 507 mm
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Transmission	6-speed
Front Brake	Dual 305 mm discs, 4-piston calipers
Rear Brake	276 mm disc, 2-piston caliper
ABS	Standard
Seat Height	850/870 mm
Fuel Capacity	20 l
Top Speed	200 km/h
