If the motorcycle is resting
on the center stand: The
motorcycle is raised too far at the
front, the center stand lifts off the
ground and the motorcycle can
tip over to the side.
When raising the motorcycle,
make sure that the center stand
remains on the ground.
Apply uniform pressure to push
front wheel stand down and
raise motorcycle.
Rear-wheel stand
Installing rear-wheel
stand
Make sure ground is level and
firm and park motorcycle.
Use rear-wheel stand with
tool number (0 402 244) with
adapter shaft (0 402 250) ap-
propriate to the motorcycle.
Set desired height of rear
wheel stand using bolts 1.
Remove the lock washer 2; to
do so, press the unlock but-
ton 3.
Push the rear-wheel stand from
the right onto the rear axle.
Mount lock washer 2 from left
by pressing release button.
Place your left hand on the
motorcycle and your right
hand on the lever 4 of the rear
wheel stand.
8
106
z
Maintenance
