Engine
Engine design Four-stroke opposed twin, air-cooled with oil-
cooled exhaust ports, installed longitudinally, two
overhead camshafts and four radially positioned
valves per cylinder, electronic engine manage-
ment.
Displacement 1170 cm
3
Cylinder bore 101 mm
Piston stroke 73 mm
Compression ratio 12.0 : 1
Nominal output 81 kW, - at engine speed: 7750 min
-1
with power reduction
OE
79 kW, - at engine speed: 7750 min
-1
with power reduction
OE
72 kW, - at engine speed: 7750 min
-1
Torque 120 Nm, - at engine speed: 6000 min
-1
Maximum engine speed max 8500 min
-1
Idle speed 1150
±50
min
-1
, Engine at regular operating tempe-
rature
10
131
z
Technical data
