BMW R 1200GS User Manual

ATTENTION
Centre stand retracts if mo-
torcycle is lifted too high
Risk of damage to parts if vehicle
topples
When raising the vehicle, make
sure that the centre stand re-
mains on the ground.
Apply uniform pressure to push
the front-wheel stand down
and raise the motorcycle.
Engine oil
Checking engine oil level
ATTENTION
Misinterpretation of oil level
reading, because oil level is
temperature-dependent (the
higher the temperature, the
higher the oil level)
Engine damage
Check the oil level only
after a lengthy ride or when
the engine is at operating
temperature.
Switch off the engine when it is
at operating temperature.
Make sure the ground is level
and firm and place the motor-
cycle on its centre stand.
Wait five minutes for the oil to
drain into the oil pan.
Check the oil level in oil-level
indicator 1.
Engine oil, specified level
between MIN and MAX marks
8
138
z Maintenance

BMW R 1200GS Specifications

General

Final Drive	Shaft drive
Displacement	1170 cc
Power	92 kW (125 hp) at 7, 750 rpm
Torque	125 Nm at 6, 500 rpm
Fuel Capacity	Approx. 20 l
Seat Height	850 / 870 mm
Front Brake	Dual 305 mm discs, 4-piston calipers
ABS	Standard
Wheelbase	1, 507 mm
Transmission	Constant mesh 6-speed gearbox with helical gear teeth
Rear Suspension	Paralever, WAD strut (travel-related damping), spring pre-load hydraulically adjustable (continuously variable) at handwheel, rebound damping adjustable
