BMW S 1000R 2015 User Manual

The setting shows briefly, then
disappears automatically.
Adjusting suspension
damping with DDC
with Dynamic Damping Control
(DDC)
OE
Switching on ignition ( 40).
Press button 1 briefly to view
the current setting.
To adjust damping:
Repeatedly press button 1 until
the setting you want to use
appears on the display.
NOTICE
You can adjust the damping
characteristic while the motor-
cycle is on the move.
The following settings are avail-
able:
SOFT: Comfortable damping
characteristic
NORM: Normal damping char-
acteristic
HARD: Sporty damping char-
acteristic
To adjust load:
Repeatedly press button 1 and
hold until the setting you want
to use appears on the display.
NOTICE
The load cannot be set while the
motorcycle is in motion.
The following settings are avail-
able:
One-up
Two-up
Removing/installing
mirrors
Removing mirror
Push protective cap 1 up.
Use the tool from the on-board
toolkit to slacken nut 2.
NOTICE
When removing the right mir-
ror, make sure that the brake-
5
85
z On the race track
ProCarManuals.com

BMW S 1000R 2015 Specifications

General

Transmission	6-speed
ABS	Standard
Engine Type	Liquid-cooled 4-stroke in-line four-cylinder engine
Max Power	160 hp (118 kW) at 11, 000 rpm
Max Torque	112 Nm (83 lb-ft) at 9, 250 rpm
Weight	207 kg (456 lbs) fully fueled
Seat Height	814 mm (32 in)
Fuel Capacity	17.5 liters (4.6 gallons)
Front Suspension	Upside-down telescopic fork, 46 mm diameter
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Dual disc brakes, floating brake discs, diameter 320 mm
Rear Brakes	Single disc brake, diameter 220 mm
