BMW S 1000R 2018 User Manual

Unlock seat lock 1 with the
ignition key.
Lift passenger seat at the rear
and then remove upwards to-
wards the rear.
Remove ignition key and place
passenger seat on a clean sur-
face with upholstered side fac-
ing downward.
Install passenger seat
Insert passenger seat into the
retainers 1 on the left and
right.
Fold passenger seat down
while pressing forwards slightly.
Lock the seat lock with the ig-
nition key.
Remove rider's seat
Press cover of driver's seat
above screws 1 forward some-
what and hold in place.
Remove screws 1.
Push the rider's seat forward,
lift it at the rear and remove it.
When doing so, make sure that
the fairing is not damaged by
the screws.
Lay the rider's seat on a clean
surface with the upholstered
side down.
4
63
z Operation

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
