BMW S 1000R 2018 User Manual

Press locking mechanisms 1.
Remove the diagnostic con-
nector 2 from the bracket 3.
The diagnosis and information
system interface can be con-
nected at the diagnostic con-
nector 2.
Secure the data link
connector
Disconnect the diagnosis and
information system interface.
Seat diagnostic connector 2
into the bracket 3.
The locks 1 engage.
Install passenger seat ( 63).
Chain
Lubricate chain
ATTENTION
Insufficient cleaning and lu-
brication of the drive chain
Increased wear
Clean and lubricate the drive
chain regularly.
After driving though water or
dust and dirt perform the lubri-
cation at shorter intervals.
Lubricate drive chain at
regular intervals.
min 497 miles (min 800 km)
Switch off ignition and engage
Neutral.
Clean drive chain with suitable
cleaning agent, dry and apply
chain lubricant.
To extend and maximize
the chain's service life
BMW Motorrad recommends
using BMW Motorrad chain
lubricant or:
Lubricant
Chain spray
Wipe off excess lubricant.
9
166
z Maintenance

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
